Harrison Offers MetalSOFT's FabriWIN® FabriTRAK® & FabriVISION®

FabriWIN®
FabriWIN(TM) is an advanced CAD/CAM system for sheet metal fabrication. The ultimate CAD/CAM solution for sheet metal fabrication, FabriWIN generates CNC programs for all your CNC punch, laser, plasma and combination machines with ONE CAD/CAM system. With over 6000 licensed users, FabriWIN is the most popular CAD/CAM system in the world.  FabriWIN utilizes Microsoft® Windows based operating systems and programs virtually all punching and cutting machines.  Combination punch/cut machines are fully supported. FabriWIN(TM) generates accurate N/C programs that reduce programming time and machine run time. Interactive CD ROM for Training and operation manuals come with FabriWIN.

These are just a few of the added/updated features to see more detailed information please contact us.  We can get you an upgrade quote!

(The Newest version of FabriWIN is version 11.0  (E-Mail us for more details)  )

1) Edit patterns in the part view of feature tree

2) Edit Parts in the sheet view of Feature Tree

3) Edit Tool information in Feature Tree

4) “Undo/Redo” function in the Draw menu

5) Multiple-Notch

6) Smooth segments

7) Round line corner

8) Explode

9) Bending

1) Turret Illustration Design

2) Add a Multiple-station into Turret

3) Export and Import a turret file

4) New “Turret Info” dialog box

5) Turret Illustration tab

6) NC code Viewer

7) Allow Adapter

8) Tool Preview

9) Turret Simulation

10) “Undo/Redo” function in the Tool menu

11) Set punching conditions when inquiring a tool

12) Tool Line Nibble

13) Tool Scribe

14) Scribe Text Tool (for Punching & Combo users)

15) Etch Text tool (for Cutting & Combo users)

16) New “Tool Sequence Priority” dialog box

1) Sheet file preview while open file

2) Export file to dxf/dwg/igs/iga file

3) History in the Output

4) Graphic Preview of Tool Priority

5) Color Parameter setting

6) Provide four types of windows style

7) Provide two types of Menu settings

8) New “Machine info” dialog box

9)) New “Material Info Dialog” box

10) User Defined Customization

11) Template Reports

12) Assembly for nesting

13) Skeleton material

14) Auto tool assignment when loading files in nesting

15) Powerful Interactive Tutorials



FabriTRAK®

FabriTRAK is an Enterprise Resource Planning (ERP) software system designed for the specific needs of the metal fabrication industry. FabriTRAK is an easy to use, unique production control and job tracking solution designed to help you increase your operating profits without increasing overhead. FabriTRAK integrates all aspects of the fabrication business process to provide vital management information in a real time setting. FabriTRAK is designed to be implemented throughout your organization.

FabriVISION Laser®

FabriVISION Laser is a high-tech laser technology based inspection machine that will increase your inspection performance, quality control processes, production capacity and overall profitability. In use for over 20 years by more than 500 customers worldwide, FabriVISON inspection series is a mature, proven tool for the validation of sheet metal parts. FabriVISION laser will reduce your first article inspection time up to 96% while at the same time increasing the accuracy of inspections by eliminating costly human errors in measurement. What might have taken hours in the past will now take minutes to complete. FabriVISION Laser increases the green light time of your shop’s machines by decreasing first-article inspection time and expensive quality control processes.

The benefits of the FabriVISION are: reduces first article inspection time to less than 5 minutes, improves utilization of fabrication machines, 100% inspection with full documentation, SPC reports available, hands off inspection (operator does not need inspection skills), quickly and accurately digitize existing parts and automatically creates CAD file from scanned parts
If We Can Be of Assistance Please
Call 817-354-4200, Fax 817-354-0723
Use our form:,Or Send us
